Alpine 1din Media Receiver BT

Specifications:
- Built-in amplifier: 4 x 50 Watts
- 2 PreOuts (2 Volts)
- Max Power Output: 4 x 50W
- FM Tuner: Tuning Range: 87.5 - 108.0 MHz
- MW Tuner: Tuning Range: 531 - 1,602 kHz
- LW Tuner: Tuning Range: 153 - 279 kHz

USB:
- USB Requirements: USB 1.1/2.0
- Max. Power Consumption: 1,000 mA
- File System: FAT 16/32

Sound Tuning:
- Subwoofer Level Adjustment: 0 to 15 dB
- Subwoofer Phase Setting: 0 degrees or 180 degrees
- High Pass Filter: Off, 80/100/120 Hz
- Low Pass Filter: Off, 80/100/120 Hz
- Bass Level Control Range: +/-7 dB at 100Hz
- Bass Center Frequency: 60/80/100/120 Hz
- Bass Band Width Adjustment (Q): 4 choices (0.5=wide, 1.0=medium, 1.5=medium, 2=narrow)
- Treble Level Control Range: +/-7 dB at 10 kHz
- Treble Center Frequency: 7.5k/10k/12.5k/15k Hz
- Treble Band Width Adjustment (Q): 2 choices (0.75=wide, 1.25=narrow)
- Mid Level Control Range: +/-7 dB
- Mid Center Frequency: 500/1k/1.5k/2.5k Hz
- Mid Band Width Adjustment (Q): 4 choices (0.75=wide, 1.0=medium, 1.25=medium, 1.5=narrow)

General:
- Power Requirement: 12V.DC
- Pre Output Voltage (Before Clipping): 2V / 10k ohms
- Aux In: 1.4V / 10k ohms
- Maximum Mounting Angle: 30 degrees
- Weight: 0.8 kg

Dimensions:
- Din Size: 1 DIN
- Chassis Size (W x H x D) mm: 178 x 50 x 177 mm
